Asenware AW-D120 is an intelligent addressable sounder base for addressable detector (Model A) and conventional detector(Model B), which can be configured with Asenware AW-FP100 Series Addressable Fire Alarm Control Panel. Each point (device) can be given specific ID, which allows the panel to continuously monitor specific addressable sounder base location (point) and give a visual and audible signal when panel enters fire alarm condition.

• Loop powered sounder
• LED indicator
• Two wire connection (easy to install)
• Can be used as a detector base
• Meet all requirement of EN 54-3:2014

  Addressable Strobe Sounder Base Technical Parameters

  Model	AW-D120 (A for addressable detector, B for conventional detector)
  Operating voltage	20~28VDC @Loop
  Operating current[@Loop 24VDC]	Standby statuss7 mA, Alarm statuss60mA with addressable detector; Alarm statuss70mA with conventional detector;
  Wiring	The promise of two bus system (Loop in, Loop out)
  Alarm SPL	≥65dB @3m
  Environmental	Temperature range: -10~50°C (14~122°F) Humidity: 5 to 95% RH, non-condensing
  Mating host	AW-FP100 series fire alarm control panel
  Size	130mm*31.2mm
  Weight	About 145g
