Description
The detector is a temperature detector using the best hot runner and is very responsive. The detector is designed to provide open area protection without wiring and easy to install and construct;
The red LED on each detector provides a local 360°visible alarm indication. They flash once every minute, indicating that the power is on and the detector is working. When an alarm occurs, the red LED is on; when the battery is low, the red LED will flash and will beep. The red LED will be on when the fire alarm is activated, until the smoke concentration is lower than the alarm threshold.
The test button is used to test whether the detector works normally; each time the buzzer is pressed, the buzzer emits a beep, the red LED flashes, and simulates a fire alarm; this button can be used for local mute during a fire.
Standalone Heat Detector Features:
Easy to install, mounting bracket included
High quality durable sensor
Loud 85dB alarm and LED warning indicator
Excellent reliability and high stability
Suitable for all families and other places where needs
Meets all requirements of latest BS5446-2 standard
| Model |
AW-D612 |
| Operating Voltage |
9VDC(with battery 6F22 ) |
| Operating current ; |
monitoring statuss8uA, alarm statuss20mA |
| Fix temperature Alarm: |
57°C (135°F) A2R |
| Rate of rise Alarm: |
≥10°C/2M A2R |
| Alarm SPL: |
≥85db@3m |
| Low battery alarm voltage |
≤7.6V |
| Battery Life |
≥1 Year |
| Indicator |
Normal: blinking Alarm: lighting |
| Environmental |
Temperature range: -10 to 50°C (14-122°F)
Humidity: 5 to 95% RH, non-condensing |
| Materials and colors |
ABS, white |
| Size |
98.6mm * 37.3mm (with cover) |
| Weight |
About 120g |
