Image sensor 1/2.7? Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens Upper Camera: 2.8mm@ F1.6, viewing angle: Diagonal 130?, Horizontal 108?, vertical 56?
Bottom Camera: [email protected], viewing angle: Diagonal 62?, Horizontal 55?, vertical 28?
PT Angle Pan: 340?, Tilt: 80?
Minimum Illumination 0.5 Lux @(F1.6, AGC ON),?0 Lux with IR (* data is obtained from EZVIZ laboratories)
Lens Mount M12
Day & Night IR-cut filter with auto switch
DNR 3D DNR
WDR Digital WDR
Black & White Night Vision 30m/98ft
Max. Resolution 2304*1296
Frame Rate Max:15fps; Self-Adaptive during network transmission
Video Compression H.265 / H.264
H.265 Type Main Profile
Video Bit Rate Ultra-HD; Hi-Def; Standard. Adaptive bit rate.
Audio Bit Rate Self-Adaptive
Max. Bitrate 3Mbps
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Support 20MHz
Security WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps,11g?:54Mbps,11n?:150Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Wired Network RJ45 ? 1(10M/100M Adaptive Ethernet Port)
Smart Alarm AI-Powered Human / Vehicle Shape Detection /Motion Detection
Auto Tracking Supports
Customized Alert Area Supports
Two-way Talk Supports
Preset Locations Supports
General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark
Local Storage Micro SD Card Slot (Up to 512GB)
Cloud Storage EZVIZ Cloud Storage
Operating Conditions -30?C to 50?C ( -22?F to 122 ?F )
humidity 95% or less (non-condensing)
IP Grade Weatherproof Design
Power Supply DC 12V/1.5A
Power Consumption MAX. 12W
Dimensions 145*116*192mm (5.71?4.57? 7.56inch)
