The Conventional Fire Alarm Control Panel 8 Zone is housed in the most attractive, modern designed, friendly user interface for easy operation and recognition. It has smaller size and easier for installation.The panel can also be ordered with a metal box.

Conventional Fire Alarm Control Panel 8 Zone

• Automatic power switchover
• 12V2.3Ah High-capacity batteries
• Fault supervision and notification
• 2 relay output circuits
• 2 sounder output circuits
• Sounders and panel buzzer silence
• Extensible application for GSM
• Meets all requirements of latest EN54 part 2 and EN54 part 4

  ITEM	8 Zone Fire alarm control Panel
  Model No.	AW-CFP2166-04-16
  Mains supply voltage	110VAC or 240VAC
  Internal power supply	27.2VDC
  Total output current limited	3A @ 240VAC
  Batteries (Default Configuration)	12V2AH*2-24VDC in Total
  End of Line device	6.8k Q,5% tolerance, 0.25W (color code-blue, grey, red, gold)
  End of line resistor value	6.8k 22,5% tolerance, 0.25W (color code-blue, grey, red, gold)
  Dimensions(mm)	395*502″124mm
  Weight (without batteries)	7kg
  Weight (with batteries)	9.6kg
  Environmental	Class A temperature range: -5 to 50°C Humidity: 5 to 95% RH, non-condensing
